Geolux VX60 Non-Contact Surface Velocity Sensor

The Geolux VX60 is a high-performance radar sensor utilizing advanced FMCW 4D radar technology to provide non-contact measurement of the water surface velocity.
Your Price Call
Stock Check Availability
Key Features
  • Contactless surface velocity measurement
  • 4D radar processing increases sensitivity while eliminating environmental disturbances
  • Robust, compact, IP68 aluminum enclosure

The Geolux VX60 is a high-performance radar sensor utilizing advanced FMCW 4D radar technology to provide measurement of the surface flow velocity. Designed for non-contact measurement applications, the VX60 enables rapid deployment above water surfaces while minimizing maintenance requirements.

The VX60 employs advanced 4D radar processing that delivers superior performance compared to conventional Doppler-based surface velocity radars. While traditional Doppler sensors are susceptible to measurement degradation from ambient interference, precipitation, and structural vibration, the VX60’s signal processing architecture ensures consistent, high-accuracy velocity measurements under all environmental conditions.

The radar operates in V-band (60 GHz) and provides flow speed readings over serial RS-232, RS-485 Modbus and SDI-12 interfaces. The instrument is compatible both with Geolux and 3rd party data loggers. An integrated MEMS sensor provides the data for automatic tilt angle compensation.

Radar Type: V-band 60 GHz FMCW radar
Distance Detection: Up to 25 meters above the water
Speed Range: 0.02 m/s to 16 m/s
Speed Resolution: 0.001 m/s
Speed Accuracy: 1% of measured value (in full measurement range)
Sampling Rate: 1 sps
IP Rating: IP68
Interfaces: RS-232 NMEA; RS-485 Modbus RTU; SDI-12; Analog 4-20mA
Connector Type: M12 circular 12-pin
Cable: 10m cable included
Input Voltage: 9 to 27 VDC
Power Consumption: 1000 mW operational; 30 mW standby
Maximal Current: <500 mA
Operating Temperature Range: -40°C to +85°C
Operating Humidity Range: 0 to 100% RH
