YSI ProQuatro Multi-Parameter Water Quality Meter

The YSI ProQuatro meter measures combinations of DO, conductivity, specific conductance, salinity, resistivity, TDS, pH, ORP, ammonium, nitrate, chloride and temperature.

America’s Premier Xylem and YSI Dealer!

Starting At $1,460.15

Stock 2 AVAILABLE

America’s Premier Xylem and YSI Dealer!

Fondriest Exclusives

Free ground shipping
Expedited repair and warranty service
Lifetime technical support
More
At Fondriest, we are committed to providing high-quality products at affordable prices with the industry's best support. Additionally, we offer:
1. Discounts
  High volume purchases lead to favorable pricing, which is passed on to the customer by way of discount off MSRP.
2. Assembly, Test and Calibration
  Sensors and instruments are assembled, tested and calibrated prior to shipment. A calibration report is included.
3. Lifetime Technical Support
  A knowledgeable staff of applications engineers provides ongoing support for the life of the product.
4. Product Training
  Applications engineers are available for webinars or personalized, on-site startup and training. Extensive measurement technology, product troubleshooting and instrument repair workshops are offered at the Field Station.
5. Extended Warranties
  Warranties extended beyond factory standards are offered on many items to ensure a lasting useful life.
6. Repair
  A factory-authorized service center provides fast turnaround product repair and annual maintenance.
7. Rental
  Rental equipment is available to minimize downtime and cover equipment needs when projects expand.
8. Communications
  Call, email or chat online with applications engineers. Email correspondence is responsive and a toll-free number is available for added convenience.
9. Quick Ship
  Many orders ship on the same day and expedited shipping is available. If a product cannot be shipped immediately, customers are notified by phone or email.

SCHEDULE DEMO

RENT THIS PRODUCT

VIEW ALL YSI PRODUCTS

Details

Specs

Contents

Documents

Q/A

Key Features

User-replaceable cables and sensors (not included with meter purchase)
Real-time salinity compensation of DO measurements
Built-in micro USB port for easy data transfer to flash drive

Overview
The YSI ProQuatro, along with its Quatro cable, allows the use of 4-ports to measure temperature/conductivity, DO, and any two ISEs among pH, ORP, ammonium, chloride, or nitrate creating an extremely powerful handheld multiparameter instrument. Sensors are not included in meter purchases.

Versatile
Connect any Professional Series cable and probe option to the instrument and use the convenient cable management kit to keep everything simple and organized. Cable options range from 1-, 4-, 10-, 20-, and 30-meter choices (up to 100-meters on DO-only cables). Use lab or field probes and switch between the two quickly. The ProQuatro makes an ideal lab BOD instrument with the proven self-stirring BOD probe (EPA Approved). A complete family of accessories also increases the versatility of the YSI ProQuatro. Choose among accessories including carrying cases, flow cells, cable weight, belt clip, and tripod.

Field Durable Features

Easy-to-install cable weights; can be daisy-chained for additional weight
Rubber, over-molded IP-67 waterproof case (even without the battery cover)
3-year instrument warranty
2-year cable warranty
Rugged cables, sensors, and military-spec connectors
Drop-tested 1 meter at all angles
Scratch-resistant lens; viewable even with polarized glasses
Instrument floats
Weighted, user-replaceable multi-sensor design

Smart Features

5,000 data set memory
Detailed on-screen Help function
Interval or single-event logging
50 Data IDs*
Password protection
Detailed GLP data
USB connection also powers the instrument
6-point cal with auto-buffer recognition

Barometer	Range: 375 to 825 mmHg Accuracy: ±1.5 mmHg from 0 to 50 °C Resolution: 0.1 mmHg
Cable Options	Standard lengths of 1, 4, 10, 20 or 30 meters with single port, dual port or Quatro cables, Lab Cables: BOD sensor includes 2-meter cable; 1 or 4 meters on lab pH, ORP and pH/ORP cables
Certifications	RoHS, CE, FCC
Country of Origin	Assembled in the USA
Display	Backlit, graphic display
Languages	English, Spanish, German, French, Italian, Norwegian, Portuguese, Japanese, Chinese (Simplified and Traditional)
Logging Capabilities	Single point or continuous with autostable feature
Memory	5000 datasets; 50 unique data identifiers
Operating Temperature	-10 to 60 °C
Power	2 alkaline C-cells provide 80 continuous hours at ambient temperature without backlight; USB power or optional wall power can be supplied via micro USB port
Response Time	2.0 mil PE = 17 seconds and 3 in/sec flow, 1.25 mil PE = 8 seconds and 6 in/sec flow, 1 mil Teflon® = 18 seconds and 12 in/sec flow
Size	8.3 cm width x 21.6 cm length x 2.3 cm depth (3.25 in. x 8.5 in. x 2.25 in.)
Storage Temperature	-20 to 70 °C
USB	Built-in micro USB port for on-the-go data exports via direct connection to the included USB stick ; user-upgradeable firmware via USB and website
Warranty	3-year instrument; 2-year cable
Waterproof	IP-67 (even with battery cover off); floats
Weight	475 grams (1.05 lbs.) with batteries

(1) ProQuatro multi-parameter instrument
(1) USB cable
(1) USB flash drive
(2) C-cell batteries

Questions & Answers

Will the ProQuatro work with the older Quatro cable assemblies that shipped with the Pro Plus meters?

Yes, the ProQuatro meter is compatible with all Quatro cable assemblies regardless of when they were manufactured. It is also compatible with the Pro10, Pro20, Pro30, Pro1020, Pro1030, and Pro2030 cable assemblies.

The ProQuatro meter is reading “Probe Temp under range”. What can I do to troubleshoot?

First, check the cable connection and ensure the temperature sensor is clean. If that does not resolve the issue, contact the Fondriest Repair department customercare@fondriest.com

Does any conductivity standard come with the 5560 temp/conductivity probe?

The 5560 temperature and conductivity probe for the YSI ProQuatro does not include any calibration solutions, these will need to be purchased seperately.

Can YSI meters and probes be recycled?

Yes, YSI has a recycling program for old equipment. Find it here: https://www.ysi.com/customer-support/recycling-disposal

It says that the DO sensor needs to be setup on the ProQuatro meter before calibration, what does that include?

The dissolved oxygen probe set-up for the ProQuatro includes setting the sensor to 'enabled' on the meter as well as selecting the type of probe that is being installed (polarographic, galvanic).

What is the difference between the 1001 pH sensor and 1001A amplified pH sensor for the ProQuatro meter?

The 1001 pH sensor works well on the 1m and 4m cables in typical applications. The 1001A amplified pH sensor has an internal pre-amplifier for improved performance with longer cables, contaminated bulkheads, and very cold waters.

Is it possible to order a ProQuatro Field Kit with cable lengths other than 4m?

The ProQuatro Field Kits are only available with 4m cables. If longer or shorter cables are needed, then it's best to order the individual components (meter, cable assembly, sensors, carrying case). As a complimentary service, Fondriest Environmental will assemble the meter and calibrate it prior to shipment.

I need to perform water quality profiles in lakes deeper than 30m. Are longer cable lengths available?

The longest cable length available with the ProQuatro meter is 30m. If a longer cable is needed for lake profiling, we recommend considering the YSI ProDSS multi-parameter water quality meter with cable lengths up to 100m and optional integrated depth sensor.

Details

Key Features

User-replaceable cables and sensors (not included with meter purchase)
Real-time salinity compensation of DO measurements
Built-in micro USB port for easy data transfer to flash drive

Easy-to-install cable weights; can be daisy-chained for additional weight
Rubber, over-molded IP-67 waterproof case (even without the battery cover)
3-year instrument warranty
2-year cable warranty
Rugged cables, sensors, and military-spec connectors
Drop-tested 1 meter at all angles
Scratch-resistant lens; viewable even with polarized glasses
Instrument floats
Weighted, user-replaceable multi-sensor design

Smart Features

5,000 data set memory
Detailed on-screen Help function
Interval or single-event logging
50 Data IDs*
Password protection
Detailed GLP data
USB connection also powers the instrument
6-point cal with auto-buffer recognition

Specs

Barometer	Range: 375 to 825 mmHg Accuracy: ±1.5 mmHg from 0 to 50 °C Resolution: 0.1 mmHg
Cable Options	Standard lengths of 1, 4, 10, 20 or 30 meters with single port, dual port or Quatro cables, Lab Cables: BOD sensor includes 2-meter cable; 1 or 4 meters on lab pH, ORP and pH/ORP cables
Certifications	RoHS, CE, FCC
Country of Origin	Assembled in the USA
Display	Backlit, graphic display
Languages	English, Spanish, German, French, Italian, Norwegian, Portuguese, Japanese, Chinese (Simplified and Traditional)
Logging Capabilities	Single point or continuous with autostable feature
Memory	5000 datasets; 50 unique data identifiers
Operating Temperature	-10 to 60 °C
Power	2 alkaline C-cells provide 80 continuous hours at ambient temperature without backlight; USB power or optional wall power can be supplied via micro USB port
Response Time	2.0 mil PE = 17 seconds and 3 in/sec flow, 1.25 mil PE = 8 seconds and 6 in/sec flow, 1 mil Teflon® = 18 seconds and 12 in/sec flow
Size	8.3 cm width x 21.6 cm length x 2.3 cm depth (3.25 in. x 8.5 in. x 2.25 in.)
Storage Temperature	-20 to 70 °C
USB	Built-in micro USB port for on-the-go data exports via direct connection to the included USB stick ; user-upgradeable firmware via USB and website
Warranty	3-year instrument; 2-year cable
Waterproof	IP-67 (even with battery cover off); floats
Weight	475 grams (1.05 lbs.) with batteries

Contents

(1) ProQuatro multi-parameter instrument
(1) USB cable
(1) USB flash drive
(2) C-cell batteries

Documents

Q/A

Questions & Answers

Will the ProQuatro work with the older Quatro cable assemblies that shipped with the Pro Plus meters?

The ProQuatro meter is reading “Probe Temp under range”. What can I do to troubleshoot?

First, check the cable connection and ensure the temperature sensor is clean. If that does not resolve the issue, contact the Fondriest Repair department customercare@fondriest.com

Does any conductivity standard come with the 5560 temp/conductivity probe?

The 5560 temperature and conductivity probe for the YSI ProQuatro does not include any calibration solutions, these will need to be purchased seperately.

Can YSI meters and probes be recycled?

Yes, YSI has a recycling program for old equipment. Find it here: https://www.ysi.com/customer-support/recycling-disposal

It says that the DO sensor needs to be setup on the ProQuatro meter before calibration, what does that include?

The dissolved oxygen probe set-up for the ProQuatro includes setting the sensor to 'enabled' on the meter as well as selecting the type of probe that is being installed (polarographic, galvanic).

What is the difference between the 1001 pH sensor and 1001A amplified pH sensor for the ProQuatro meter?

Is it possible to order a ProQuatro Field Kit with cable lengths other than 4m?

I need to perform water quality profiles in lakes deeper than 30m. Are longer cable lengths available?

Select Options

Products 0 Item Selected


Part #

Product Description

Price

Stock

Select

606950

ProQuatro multi-parameter water quality meter (cable/sensors sold separately)

$1,460.15

2 Available

$1,460.15

606966

ProQuatro Pol DO/pH/Cond 4m Field Kit: Includes ProQuatro meter, Quatro 4m cable, 2003 polarographic DO sensor, 1001 pH sensor & 3075 case

$3,824.70

Check Availability

$3,824.70

606968

ProQuatro Gal DO/pH/Cond 4m Field Kit: Includes ProQuatro meter, Quatro 4m cable, 2002 galvanic DO sensor, 1001 pH sensor & 3075 case

$4,068.85

Check Availability

$4,068.85

606967

ProQuatro Pol DO/pH/ORP/Cond 4m Field Kit: Includes ProQuatro meter, Quatro 4m cable, 2003 polarographic DO sensor, 1001 pH sensor, 1002 ORP sensor & 3075 case

$4,085.95

Check Availability

$4,085.95

606969

ProQuatro Gal DO/pH/ORP/Cond 4m Field Kit: Includes ProQuatro meter, Quatro 4m cable, 2002 galvanic DO sensor, 1001 pH sensor, 1002 ORP sensor & 3075 case

$4,351.95

Check Availability

$4,351.95

Accessories 0 Item Selected


Part #

Product Description

Price

Stock

Select

605790-1

Quatro cable assembly (ISE/ISE/DO/Cond) with temperature/conductivity sensor, 1m

$1,913.30

1 Available

$1,913.30

605790-4

Quatro cable assembly (ISE/ISE/DO/Cond) with temperature/conductivity sensor, 4m

$1,960.80

2 Available

$1,960.80

605790-10

Quatro cable assembly (ISE/ISE/DO/Cond) with temperature/conductivity sensor, 10m

$2,041.55

Check Availability

$2,041.55

605790-20

Quatro cable assembly (ISE/ISE/DO/Cond) with temperature/conductivity sensor, 20m

$2,347.45

Check Availability

$2,347.45

605790-30

Quatro cable assembly (ISE/ISE/DO/Cond) with temperature/conductivity sensor, 30m

$2,542.20

Check Availability

$2,542.20

605202

2002 galvanic DO sensor with yellow 1.25 mil PE membrane kit, Pro Series

$239.40

3 Available

$239.40

605203

2003 polarographic DO sensor with yellow 1.25 mil PE membrane kit, Pro Series

$239.40

9 Available

$239.40

607203

2003B polarographic DO sensor with blue 2.00 mil PE membrane kit, Pro Series

$255.55

Check Availability

$255.55

605101

1001 pH (ISE) sensor, Pro Series

$223.25

8 Available

$223.25

605323

1001A amplified pH (ISE) sensor

$299.25

3 Available

$299.25

605102

1002 ORP (ISE) sensor, Pro Series

$266.95

3 Available

$266.95

605104

1004 ammonium (ISE) sensor, Pro Series

$473.10

Check Availability

$473.10

605105

1005 chloride (ISE) sensor, Pro Series

$504.45

Check Availability

$504.45

605106

1006 nitrate (ISE) sensor, Pro Series

$473.10

Check Availability

$473.10

606850

6850 flow cell for Pro Series Quatro cable assembly

$516.80

2 Available

$516.80

603056

3056 flow cell mounting spike

$45.60

Check Availability

$45.60

603162

6262 small soft-sided carrying case for Pro Series meters with up to 10m cable

$130.15

2 Available

$130.15

603075

3075 soft-sided carrying case for Pro Series meters

$179.55

2 Available

$179.55

603074

3074 hard-sided carrying case for Pro Series meters

$388.55

4 Available

$388.55

063507

4654 tripod, for Pro Series displays

$61.75

Check Availability

$61.75

FNCS1000-P

Conductivity standard, 1,000 uS, 500mL bottle

$20.42

1 Available

$20.42

FNCS9910-P

Conductivity standard, 10,000 uS, 500mL bottle

$25.81

Check Availability

$25.81

FNCS9945-P

Conductivity standard, 45,000 uS, 500mL bottle

$41.78

Check Availability

$41.78

FNZE4175-P

Zero oxygen standard, 500mL bottle

$17.64

2 Available

$17.64

FNBU5004-P

pH 4 calibration buffer, 500mL bottle

$15.43

5 Available

$15.43

FNBU5007-P

pH 7 calibration buffer, 500mL bottle

$15.43

5 Available

$15.43

FNBU5010-P

pH 10 calibration buffer, 500mL bottle

$15.43

5 Available

$15.43

FNOR4200-P

ORP standard, 200mV, 500mL bottle

$53.97

2 Available

$53.97

FNNS4601-P

Nitrate standard as N, 1 mg/L, 500mL bottle

$53.57

Check Availability

$53.57

FNNS4700-P

Nitrate standard as N, 100 mg/L, 500mL bottle

$42.98

Check Availability

$42.98

FNAS1001-P

Ammonia standard as N, 1 mg/L, 500mL bottle

$30.92

Check Availability

$30.92

FNAS1100-P

Ammonia standard as N, 100 mg/L, 500mL bottle

$44.49

Check Availability

$44.49

FNCH7305-P

Chloride standard as Cl, 10 mg/L, 500mL bottle

$31.96

Check Availability

$31.96

FNCH7360-P

Chloride standard as Cl, 1000 mg/L, 500mL bottle

$32.05

Check Availability

$32.05

Notice: At least 1 product is not available to purchase online

PRODUCT VIDEOS

Customer Stories

Chesapeake Bay Sees Largest Oyster Reef Restoration in the World Completed

The largest oyster reef restoration in the world was recently completed in the United States’ largest estuary: the Chesapeake Bay. The project is the result of a 10-year, over $100 million commitment from local, state, and federal agencies to restore one of the bay’s most vital keystone species. The Chesapeake has lost 99% of its historic oyster numbers, with cascading negative effects on the entire bay ecosystem. “When it comes to oysters, we’re down to 1% of our historic number of oysters,” says NOAA’s Chesapeake Bay Oyster Restoration Program Manager Stephanie Westby. “And when you lose 99% of your oysters, you lose 99% of your reef habitat, and you lose 99% of everything.

Read the Full Article

How Ohio’s Inland Fisheries Research Unit Uses Science to Improve Fishing

Ohio is a state defined by its water bodies, with Lake Erie to the north and the Ohio River meandering along its southern and eastern border. Within these boundaries are the Buckeye State’s inland waterways, sporting over 60,000 miles of rivers and streams and 112,000 surface acres of lakes and reservoirs, according to the Ohio Division of Wildlife . This plethora of water also offers ample opportunities for anglers to pursue the variety of sportfish that can be found in Ohio. While Lake Erie is well-known for its recreational opportunities, Ohio’s inland waterways also provide plenty of opportunities to pursue everything from bluegill to catfish. These thousands of miles of water are monitored and researched by many agencies and organizations within the state.

Read the Full Article

Monitoring for a Cause: How Climate Change Impacts Freshwater Organisms in Southern Appalachia

Climate change and subsequent shifts in weather events are changing aquatic ecosystems across the world. Streams drying up in droughts, floods overflowing rivers and displacing freshwater organisms, climbing temperatures making environments unsuitable for native species, and other stressors are all changing key habitats and shaping populations in impacted regions like Southern Appalachia. Michael Gangloff, Professor of Biology at Appalachian State University, has been monitoring waterways and freshwater taxa under duress in the southeastern US for 27 years, measuring abundance, size, and condition of local taxa as well as quantifying changes to physical habitat conditions through long-term monitoring at established sites.

Read the Full Article

Email Address		INVALID
Shipping Zip Code		INVALID

Ground Shipping:	Products shipped via ground service are typically delivered within five business days after shipment.
2-Day Shipping:	For an additional charge, Fondriest offers 2-day shipping for most products. Products shipped via two-day service prior to 4:00 p.m. EST are usually delivered by 7:00 p.m. local time two business days after shipment.
Overnight Delivery:	For an additional charge, Fondriest offers overnight shipping for most products. Products shipped via overnight service prior to 4:00 p.m. EST are normally delivered by 7:00 p.m. local time one business day after shipment. Earlier overnight delivery options may also be available, depending on the destination.
Your Account:	For no additional charge, Fondriest can ship on third-party customer accounts via UPS and FedEx. Note that FedEx Ground shipments are picked up the following business day, and Express shipments must be made before 1:00 p.m. EST to ensure same-day pick-up.

YSI ProQuatro Multi-Parameter Water Quality Meter

Shipping, Delivery, Order Processing & Product Availability

Delivery Time

Shipping and Delivery Estimates

Shipping Options

Signature Required on Most Deliveries

Undeliverable Packages

Failed Delivery Attempts

Order Processing

Product Availability

Select Options

PRODUCT VIDEOS

Customer Stories

Chesapeake Bay Sees Largest Oyster Reef Restoration in the World Completed

How Ohio’s Inland Fisheries Research Unit Uses Science to Improve Fishing

Monitoring for a Cause: How Climate Change Impacts Freshwater Organisms in Southern Appalachia
